INS-11013-3 | Tonometer Goldmann-X Type

The INS-11013-3 Goldmann Applanation Tonometer (X-Type) is designed for accurate intraocular pressure measurement during slit-lamp examinations. Its X-Type configuration is ideal for compatible Zeiss-style slit lamps and other systems equipped with a suspension-arm interface.

Outstanding Features

Goldmann Applanation Principle

The INS-11013-3 measures intraocular pressure using the established Goldmann applanation principle. A pressure-measuring probe containing a prism gently flattens a precisely defined area of the patient's cornea.

X-Type Configuration

The X-Type configuration is designed for use with compatible Zeiss-style slit lamps and other slit-lamp systems featuring a suspension-arm mounting interface.

Precise Corneal Applanation

The instrument applanates a circular corneal area measuring 3.06 mm in diameter. Because the flattened area is small, changes in intraocular pressure caused by the measuring force are minimized.

Fluorescein Observation

Under slit-lamp magnification with fluorescein and blue-light illumination, the practitioner observes two green semicircles and adjusts the measuring drum until their inner edges align.

Wide Measurement Range

The tonometer provides a measurement range from 0 to 10.6 kPa, equivalent to approximately 0 to 80 mmHg, supporting routine IOP examinations and elevated-pressure assessments.

7 mm Measuring Probe

The instrument incorporates a 7 mm pressure-measuring probe with an integrated prism for use during Goldmann applanation examinations.

Controlled Probe Movement

The measuring probe provides a 3 mm movement range for controlled positioning and alignment during the examination.

✅ The Opti+ INS-11013-3 Goldmann Applanation Tonometer provides precise IOP measurement, convenient X-Type compatibility with Zeiss-style slit lamps, and a wide measurement range for dependable clinical examinations.
